IL-s-64045/103 (AR)
7 January 1991
MILITARY SPECIFICATION SHEET
S C A L E , GRAPHICAL FIRING, HE M107, LOW ANGLE,
(155-AM-2), CHARGES 3&4, (P/N 11785434-112)
This specification is approved for use by all Departments
a n d Agencies of the Department of Defense.
The complete requirements for procuring this item described
herein shall consist of this document and the latest issue of
s p e c i f i c a t i o n MIL-S-64045.
ACCURACY DATA
Elevation
T i m e of Flight
RANGE
CHARGE
(meters)
FS M582
(meters)
(seconds)
6.0±0.l
109.5±0.5
1600
3
9.3±0.1
170.0±0.5
2400
218.0±0.5
11.8±0.l
3000
308.0±l.0
16.4±0.1
4000
8.l±0.1
130.0±0.5
2400
4
179.0±0.5
11.0±0.1
3200
267.0±l.0
16.2±0.l
4500
390.0±l.0
23.0±0.1
6000
Preparing activity:
Custodian:
Army-AR
Army-AR
( p r o j e c t 1220-A436)
l of l
FSC 1220
AMSMC N/A
