MIL-S-64045/106 (AR)
7 January 1991
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, HE M760, LOW ANGLE
(105-AS-2), CHARGE 8, (P/N 11785434-115)
This specification is approved for use by all Departments
a n d Agencies of the Department of Defense.
The complete requirements for procuring this item described
herein shall consist of this document and the latest issue of
specification MIL-S-64045.
ACCURACY DATA
2
l
T.A.G.³
T.B.G.
Range
CHARGE
12540±30
13080±30
9000
8
l1900±30
10200
1 . Range in meters on C scale
2 . Range in meters on T.B.G. scale (Target below gun)
3 . Rnage in meters on T.A.G. scale (Target above gun)
Preparing activity:
Custodian:
Army-AR
Army-AR
( P r o j e c t 1220-A439)
l of l
FSC 1220
AMSMC N/A
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
