MIL-s-64045/16
15 July 1983
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, HE M107, LOW ANGLE, W\ICM,
(155-Q-4) Chgs 4 & 5, (P/N 11785434-16)
T h i s specification is approved for use by all Departments and
A g e n c i e s of the Department of Defense.
T h e complete requirements for procuring this item described herein
shall consist of this document and the latest issue of specifica-
t i o n MIL-S-54045
ACCURACY DATA
Range
Elevation
Drift
Fuze
(meters)
(mils]
FS
Charge
(mils)
Settinq
4
3100
1.72±1
.20±.01
4±1
10.5±0.1
15±1
7500t
32.7±0.1
581±1
.06±.01
4000
5
182±1
4±1
12.4±0.1
.17±.01
9000
571±1
.06±.01
14±1
354±0.1
Custodian:
PreParinG Activity
ARMY-AR
ARMY - AR
Project No.1220-A293
l of l
