MIL-S-64045/30 (AS)
15 July 1983
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, HE M483A1, LOW ANGLE,
(155-AK-2) Chgs 4 + 5, (P/N 11785434-30)
T h i s specification is approved for use by all Departments and
A g e n c i e s of the Department of Defense.
T h e complete requirements for procuring this item described herein
shall consist of this document and the latest issue of Specifica-
t i o n MIL-S-64045
ACCURACY DATA
Range
Elevation
Drift
Fuze
Charqe
(meters)
(mils]
(mils)
Setting
FS
4
4000
262±1
5±1
15.2±0.1
.14±.01
6500
527±1
11±1
28.9±.01
.07±.01
5
5000
258±1
4±1
17.0±0.1
.12±.01
8500
13±1
582±1
35.6±.01
.06±.01
Custodian:
Preparing Activity
ARMY-AR
ARMY-AR
P r o j e c t No. 1220-A293/30
l of l
