MIL-S-64045/39(AR)
15 July 1983
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, HE M107, LOW ANGLE, W/ICM,
(155-AM-1) Chgs 7 + 8, (P/N 11785434-39)
T h i s specification is approved for use by all Departments and
A g e n c i e s of the Department of Defense.
T h e complete requirements for procuring this item described herein
shall consist of this document and the latest issue of Specifica-
t i o n MIL-S-64045
ACCURACY DATA
Fuze
Drift
Elevation
Range
FS
Setting
(mils)
(mils)
(meters)
Charqe
.08±.01
24.8±.01
10±1
267±1
9000
7
.04±.01
48.8±.01
23±1
608±1
14000
.08±.01
27.6±.01
9±1
248±1
11000
8
.04±.01
56.0±.01
24±1
602±1
17000
Preparing Activity
Custodian:
ARMY-AR
ARMY-AR
Project No. 1220-A293/3
1 of 1
