MIL-S-64045/57A (AR)
24 September 1985
SUPERSEDING
MIL-S-64045/57
15 July 1983
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, M712 CLGP, LOW ANGLE,
(155-AS-0) Chgs 7WG & 8, (P/N 11785434-57)
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The complete requirements for procuring this item described herein shall consist
of this document and the latest issue of Specification MIL-S-64045.
ACCURACY DATA
Switch
Range
Elevation
Time of Flight
Des Ti
Charge
Set
(mils)
(seconds)
(seconds)
(meter)
31±1
57
WG(444m)
11000
49.5±0.1
650±1
33±1
696 + 1
11000
61
50.8 ±0.1
50±1
13500
784±1
69.8±0.1
57
54±1
864±1
73.8±0.1
13500
61
14±1
12±1
318±1
26.9±0.1
8
8500
21±1
27±1
570±1
11000
42.8±0.1
Custodian:
Preparing activity:
Army-AR
Army-AR
Project No. 1220-A311
FSC 1220
AMSC N/A
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
