SUPERSEDING
MIL-S-64045/72
15 July 1983
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, HE
LOW ANGLE,
(8-Q-1) CHGS 5 6, (P/N 11785434-72)
This specification sheet is approved for use by all Departments and Agencies of the Department of
Defense.
The complete requirements for procuring this item described here in shall consist of this document
and the latest issue of Specification MIL-S-64045.
ACCURACY DATA
Range
Charge
Elevation
Drift
Fuse
FS
(meters)
(mils)
(mils)
Setting
18.0
0.1
1
6000
5
0.1
34.4
1
1
10000
496
23.6
1
0.1
8500
268
6
42.6
0.1
1
13000
543
Custodian:
Preparing activity:
Army-AR
Army-AR
(Project 1220-0036)
AMSC N/A
1
FSC 1220
