(AR)
15 October 2001
SUPERSEDING
MIL-S-64045/73
15 July 1983
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, HE M106, LOW ANGLE,
(8-Q-l) CHGS 7 8, (P/N 11785434-73)
This specification sheet is approved for use by all Departments and Agencies of the Department of
Defense.
The complete requirements for procuring this item described here in shall consist of this document
and the latest issue of Specification MIL-S-64045.
ACCURACY DATA
Drift
Elevation
Range
FS
Fuse
Charge
(mils)
(meters)
Setting
7
10000
240
1
25.3
0.1
16000
1
1
0.1
596
51.4
8
11000
200
1
24.3
0.1
20000
692
1
65.5
0.1
Custodian:
Preparing activity:
Army-AR
Army-AR
(Project 1220-0037)
1
FSC 1220
AMSC N/A
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
