MIL-S-64045/79 (AR)
15 JUIY 1983
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, HE M650, LOW ANGLE, W/XM753,
( 8 - S - 1 ) Chgs 1G + 2G, (P/N 11785434-79)
This specification is approved for use by all Departments and
A g e n c i e s of the Department of Defense.
The complete requirements for procuring this item described herein
shall consist of this document and the latest issue of Specifica-
t i o n MIL-S-64045
ACCURACY DATA
Drift
Fuze
Range
Elevation
Settinq
FS
(meters)
(mils)
Charge
(mils)
1G
8±1
20.8±0.1
430±1
.10±.01
4500
16±1
31.4±0.1
.07±.01
685±1
5700
7±1
2G
21.0±0.1
.10±.01
396±1
5000
689±1
1.5±1
34.3±0.1
.06±.01
6700
Custodian:
Preparing Activity
ARMY-AR
ARMY-AR
Project No. 1220-A293/79
1 of 1
