MIL-S-G4045/8
15 July 1983
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, HE Ml, LOW ANGLE W/ICM,
(105-AS-2) Chgs 1 + 3, (P/N 11785434-8)
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The complete requirements for procuring this item described herein
shall consist of this document and the latest issue of Specifica-
tion MIL-S-64045
ACCURACY DATA
Fuze
Drift
Range
Elevation
FS
Settinq
(meters)
(roils)
(roils)
Charqe
.22±.01
4±1
9.3±0.1
1
234±1
1800
13±1
22.0±0.1
.09±.01
587±1
3500
.21±.01
3±1
9.9±0.1
2300
207±1
3
15±1
27.7±0.1
.08±.01
625±1
5000
Custodian:
Preparing Activity
ARMY - AR
ARMY - AR
Project
No.
1220-A293
1 of 1
