MIL-S-64045/80
15 July 1983
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL FIRING, HE M650, LOW ANGLE, W/XM753,
(8-S-1) Chgs 3G + 4G, (P/N 11785434-80)
This specification is approved for use by all Departments and
A g e n c i e s of the Department of Defense.
T h e complete requirements for procuring this item described herein
shall consist of this document and the latest issue of Specifica-
t i o n MIL-S-64045
ACCURACY DATA
Range
Elevation
Drift
Fuze
Charge
(meters)
(mils)
FS
(mils)
Setting
6±1
359±1
3G
5600
21.1±0.1
1.0±.01
694±1
8000
15±1
37.8±0.1
.06±.01
6±1
4G
6200
330±1
21.3±0.1
.10±.01
9400
16±1
656±1
40.5±0.1
.05±.01
Preparing Activity
Custodian:
ARMY-AR
ARMY-AR
Project No. 1220-A293/8
1 of 1
