MIL-S-64045/99(AR)
1 February 1987
MILITARY SPECIFICATION SHEET
SCALE, GRAPHICAL SITE, HE M107.
( 1 5 5 - A M - 2 ) , (P/N 11785434-107)
T h i s specification is is approved for use by all Departments and
A g e n c i e s of the Department of Defense.
The complete requirements for procuring this item described
herein shall consist of this document and the latest issue of
Specification MIL-S-64045.
ACCURACY DATA
T.A.G.
T.B.G.
RANGE
CHARGE
2150
±
10
2180
±
10
2100
2
2700
±
20
2670
±
20
2500
3140
±
10
3140
±
20
3000
3
3880
±
20
3790
±
20
3500
4240
±
20
4210
±
20
4000
4
5000
±
20
4880
±
20
4500
4650
±
20
4640
±
20
4500
5
6800
±
40
6550
±
40
6000
1. Range in meters on C scale.
2. Range in meters on T.B.G. scale (Target below gun.
3 . Range in xneters on T.A.G. scale (Target above gun).
Preparing activity:
Custodian:
Army-AR
Army-AR
(Project 1220-A355)
FSC 1220
lofl
AMSC N/A
